TransX-SE-Pro adopts PLC communication and supports the HomePlug Green PHY protocol. National standard charging controllers can comply with DIN 70121:2014, ISO 15118-1:2019, ISO 15118-2:2014, ISO 15118-3:2015, ISO 15118-4:2018, ISO 15118-5:2018, SAE J 2847-2:2015 and ISO 15118-20:2022 via protocol converters.During actual charging interaction, the product features intelligent protocol self-adaptation. It can seamlessly and dynamically switch among DIN 70121, ISO 15118-2 and ISO 15118-20 according to EVCC requirements of electric vehicles, ensuring high efficiency and compatibility throughout the charging process.
TransX-SE-Pro supports communication with charging controllers via CAN bus, serial ports and Ethernet ports, enabling flexible system access.
The power and communication interfaces of TransX-SE-Pro adopt fully isolated design, with high-level ESD and surge protection, delivering outstanding reliability. It supports functions including online charging data logging, platform data reading, firmware online upgrading and remote control. These functions greatly facilitate on-site fault diagnosis, accelerate troubleshooting efficiency and reduce after-sales operation and maintenance costs.
